Slimline Channel Drain
1000mm Omega Channel Drain - Brushed. No legs.
Available in 6 cover plate lengths from 530.5mm to 1130.5mm
Choice of 2 finishes - brushed or polished
Highest quality grade 304 Stainless Steel cover plate
Cover plate reversible to accommodate tiles up to 8mm
Frame height adjustable to suit tiles up to 16mm
Supplied with 50mm water seal trap and adjustable height support legs
Flow Rate 54 litres per minute, calculated under a constant 120mm head of water
- CD1000-O-B948mm
- CD1000-O-P948mm
- CD1200-O-B1148mm
- CD1200-O-P1148mm
- CD600-O-B548mm
- CD600-O-P548mm
- CD700-O-B648mm
CD700-O-P648mm
CD800-O-B748mm
CD800-O-P748mm
CD900-O-B848mm
CD900-O-P848mm
Downloads
Everything you need in one box!
Every McAlpine Channel Drain comes complete with body, cover plate, trap with UK outlet and accessories, so ordering could not be simpler. McAlpine Channel Drains achieve a flow rate of 54 litres per minute when tested in accordance with Clause 5 of BS EN 274 2:2002.
Standard Channel Drains
Watch our video giving an overview of our channel drains and how they are installed.
Details
Everything you need in one box!
Every McAlpine Channel Drain comes complete with body, cover plate, trap with UK outlet and accessories, so ordering could not be simpler. McAlpine Channel Drains achieve a flow rate of 54 litres per minute when tested in accordance with Clause 5 of BS EN 274 2:2002.
Standard Channel Drains
Watch our video giving an overview of our channel drains and how they are installed.
